TRIRON MPPT Solar Charge Controller 10 / 20 / 30 / 40 Amps

Description TRIRON MPPT N Series controller with ultra-fast tracking speed and high tracking efficiency greater than 99.5%. TRIRON N Series improve energy utilisation by 10% – 30% compared to PWM charging method. Peak DC/DC conversion efficiency of 98%. Compatible with Lead-Acid and Lithium Batteries. Temperature compensation for lead-acid batteries with optional sensor. Load timer settings can be configured with Controller, Windows PC Software or Android App. Dual USB ports for device charging (5V DC/2.2 Amp). Wide operating temperature range -25°C ~ 55°C, suitable for Solar systems in Marine, RV, Home, Communication Base Stations, Street Lighting, and Field Monitoring equipment. Usage & Connection Options: Control and Monitoring Options: Inbuilt LCD Display. Adjust parameters, control and monitor controller using remote MT50, PC or Android App. Software download required. Optional Communication Cable (USB to RS485) required for PC connection.  OTG – USB Adapter required for Mobile Phone. Electrical Specification: Parameter TRIRON 1206N (10 Amp) TRIRON 2206N (20 Amp) TRIRON 3210N (30 Amp) TRIRON 4210N (40 Amp) Nominal System Voltage 12 / 24 V DC Auto Detect Rated Charge & Discharge Current 10A 20A 30A 40A Battery Voltage Range 8V ~ 32V Max. PV Open Circuit Voltage 60V (-25°C), 46V ( 55°C) 100V (-25°C), 92V ( 55°C) MPP Voltage Range (Battery voltage 2V) ~ 36V (Battery voltage 2V) ~ 72V Max. PV Input Power 390W (12V), 780W (24V) 780W (12V), 1560W (24V) 1170W (12V), 2340W (24V) 1560W (12V), 3120W (24V) Battery Type Lead Acid (Gel / Sealed / Flooded / User Set), Lithium (LiFePO4 / Li-NiCoMn / User Set) Temperature Compensation Coefficient -3mV/℃, 2V (Default), Lead Acid Only Grounding Common Negative USB Interface Dual Port, 5VDC / 2.2A (Total) RS485 Interface 5VDC / 100mA Self Consumption ≤14mA (12V)；≤15mA (24V)   Environment Specification: Operating Temperature Range -25°C ~ 55°C Storage Temperature Range -20℃ ~ 70℃ Relative Humidity ≤95%, N.C Enclosure IP30   Physical Characteristics: Parameter TRIRON 1206N (10 Amp) TRIRON 2206N (20 Amp) TRIRON 3210N (30 Amp) TRIRON 4210N (40 Amp) Dimension 135×180.8×47.3mm 150×216×56.7mm 158×238.3×62.7mm 183×256.8×66.7mm Mounting Dimension 126×150mm 141×170mm 158×200mm 174×220mm Terminal 12AWG(4mm ) 6AWG(16mm ) 6AWG(16mm ) 6AWG(16mm ) Recommended Cable 12AWG(4mm ) 10AWG(6mm ) 8AWG(10mm ) 6AWG(16mm ) Weight 0.56kg 0.92kg 1.35kg 2.06kg   Full Protection Functions: PV Over Current, PV Short Circuit, Lithium Battery low temperature, Night Reverse charging, Battery & PV reverse polarity, Battery over discharge, Battery over heat, Battery over voltage, Load Short Circuit, Load Overload, and Controller overheating. CE, RoHS.
